How Solar Energy Heats Liquids of Different Colors


Published on Sep 16, 2023

Abstract

The objective: Students will discover how liquids with the colors along the spectrum respond when heated by the sun.

Research Questions:

How do frequencies correlate with wavelengths?

How is color temperature applied to applications such as lighting and photography? Why is it important?

Why does the sun appear to “change colors” depending on its position in the sky?

The visible spectrum is the portion of the electromagnetic spectrum that can be seen by the human eye. It consists of seven colors: red, orange, yellow, green, cyan/indigo, blue, and violet. These are the colors of the rainbow, and each has a different frequency and wavelength. For example, red has the longest wavelength and violet has the shortest. In this experiment, we'll turn the colors of the rainbow into liquid form in order to discover how hot each one becomes in sunlight

How Solar Energy Heats Liquid

Materials:

1. Seven shades of food coloring

2. Water

3. Eight thermometers

4. Eight clear drinking glasses

5. Surface to set those glasses on

6. Stirring sticks/ spoons

7. Sufficient sunlight (aim for really bright sunlight which is usually around noon-2pm)

8. Pen and paper for notes

Experimental Procedure

1. First we are going to prepare our colorful mixtures. Fill each of the eight drinking glasses up with room temperature water and leave an inch of space at the opening.

2. Carefully squeez e just three drops of food coloring in each color, in all but one glass (that is going to be the control). You may have to mix certain primary colors to get a secondary color. For example, you may have to combine equal amounts of red and yellow to get orange. Just follow the color wheel or the instructions provided on the box of food coloring for this. Stir each glass and mix well until well blended.

3. Carefully place a thermometer into each glass and note the temperature of the water.

4 . Take the eight glasses and place under direct sunlight.

5. Observe as the temperature rises in the liquid in 10-minute intervals. Do not touch any hot surfaces at this point.

6. After at least two hours under the sun, observe the temperatures of the liquids in each glass and record your results. Which one had the highest temperature? The least?

7. If you are still curious, why not try this experiment but at different concentrations of food coloring? This will be fun as it will also investigate transparency and opacity/ lightness and darkness of colors.

References:

http://science.hq.nasa.gov/kids/imagers/ems/visible.html

http://en.wikipedia.org/wiki/Electromagnetic_spectrum

http://www.3drender.com/glossary/colortemp.htm

http://www.betterphoto.com/article.asp?id=24

http://www.howeverythingworks.org/sunlight.html

http://www.colormatters.com/colortheory.html

John C. D. Brand (1995). Lines of light: the sources of dispersive spectroscopy, 1800-1930 CRC Press. p. 30–32. ISBN 9782884 4 91631. http://books.google.com/?id=sKx0IBC22p4 C&pg=PA30&dq=light+wavelength+color++young+fresnel

Priest, Irwin G. (1923)."The colorimetry and photometry of daylight ·and incandescent illuminants by the method of rotatory dispersion". JOSA 7 (12): 1175–1209.

Science Fair Project : Grade Level: 4th - 6th;
